Description

Rated Power (8ohm): 4x1200W
Rated Power (4ohm): 4x2400W
Rated Power (Bridge 8ohm): 2x3500W
Frequency Response: 20Hz-20kHz: ±0.1./0.3dB(1W/8ohm)
THD+N: 1W/8Ω<0,05
Intermodulation Distortion: 60Hz & 7k 1W/8Ω
Damping Factor: 200:1kHz@8Ω
SNR: >100dB
Slew Rate: 70xstandrd
Input Impedance: 20 kohm (Balanced) / 10 kohm (Unbalanced)
Supply Voltage: AC~200-240V /50=60Hz
Cooling: Air flow from front to rear
Protection: Soft start, Dc, short circuit, over load,
clip limit, over heat, progressive volume Conector
Input: XLR-F,TRS,XLR-F,XLR-M
Output: Two red and black binding posts Indictor
Front panel: Front panel indicator: signal,clip,protect,
power indicator,bridge,parallel power switch, volume, control knob
Rear panel: Stereo / parallel / bridge switch, input sensitivity switch,
low pass filler, high pass fillter, grounding switch
